PROLIGHTS-108658
Prolights LumiPix9UHE
9x8W RGBWAP/FC high-efficiency LED source. LumiPix 9UHE is a 1 m linear LED batten using an innovative optic system combined with a new light source which performs a colour mixing of 6 primary colours - RGBWA. The light source is composed of 9x8W high-efficiency RGBWAP/FC LED offering a more advanced chromatic synthesis than projectors of the previous generation, with full control of saturation and colour temperature on the whole spectrum. LumiPix 9UHE offers a 3 section control of the LED plate to generate a wide range of dynamic light effects.
Price on request
Downloads
| Parameter | Value |
|---|---|
| CRI | 75 |
| Power | 72 W |
| Weight | 3.2 kg |
| Emitters | Red / Green / Blue / White / Amber / Purple |
| Features | Dimmer / Shutter-Strobe / Additive color mixing / Effects |
| Revision | Rev 002 |
| Beam type | Wash |
| Long name | LumiPix9UHE |
| Beam angle | 23° |
| Dimensions | 63 × 144 × 1000 mm |
| Short name | LPix9UHE |
| DMX channels | 6 / 9 / 11 / 18 / 23 |
| Fixture UUID | CAABAE80-1B9C-41CA-A076-747D5236EA6A |
| GDTF version | 1.2 |
| Luminous flux | 2 070 lm |
| Color temperature | 6500 K |
| Operating temperature | -20 to 45 °C |
| DMX modes | 6ch | 9ch | 11ch | 18ch | 23ch |
