ASTERA-107948
Astera LED Technology AX2 100
LED PAR light with RGB colour mixing, a 21° beam and 165 DMX modes.
Price on request
Downloads
| Parameter | Value |
|---|---|
| CRI | 100 |
| Power | 80 W |
| Weight | 7.4 kg |
| Emitters | Red / Green / Blue / White Point |
| Features | Dimmer / Shutter-Strobe / Additive color mixing / Color wheel / Color temperature control |
| Revision | Extended Modes |
| Beam type | Wash |
| DMX modes | 1: RGB / Pixel = 1; Strobe = Off (3 ch) / 2: RGBW / Pixel = 1; Strobe = Off (4 ch) / 3: RGBAW / Pixel = 1; Strobe = Off (5 ch) / 4: DIM RGB / Pixel = 1; Strobe = Off (4 ch) / 5: DIM RGBW / Pixel = 1; Strobe = Off (5 ch) / 6: DIM RGBAW / Pixel = 1; Strobe = Off (6 ch) / 7: RGB CCT DIM IND / Pixel = 1; Strobe = Off (6 ch) / 8: RGBS / Pixel = 1; Strobe = On (4 ch) / 9: RGBWS / Pixel = 1; Strobe = On (5 ch) / 10: RGBAWS / Pixel = 1; Strobe = On (6 ch) / 11: DIM RGBS / Pixel = 1; Strobe = On (5 ch) / 12: DIM RGBWS / Pixel = 1; Strobe = On (6 ch) / 13: DIM RGBAWS / Pixel = 1; Strobe = On (7 ch) / 14: RGB CCT DIM IND S / Pixel = 1; Strobe = On (7 ch) / 15: Effect Mode Fix (13 ch) / 16: Effect Mode RGB (21 ch) / 17: RGB*RGB* / Pixel = 4; Strobe = Off (15 ch) / 18: RGB RGB / Pixel = 4; Strobe = Off (12 ch) / 19: RGBW RGBW / Pixel = 4; Strobe = Off (16 ch) / 20: RGBAW RGBAW / Pixel = 4; Strobe = Off (20 ch) / 21: DIM RGB DIM RGB / Pixel = 4; Strobe = Off (16 ch) / 22: DIM RGBW DIM RGBW / Pixel = 4; Strobe = Off (20 ch) / 23: DIM RGBAW DIM RGBAW / Pixel = 4; Strobe = Off (24 ch) / 24: RGB CCT DIM IND / Pixel = 4; Strobe = Off (24 ch) / 25: RGB*RGBS / Pixel = 4; Strobe = Single (15 ch) / 26: RGB RGB S / Pixel = 4; Strobe = Single (13 ch) / 27: RGBW RGBW S / Pixel = 4; Strobe = Single (17 ch) / 28: RGBAW RGBAW S / Pixel = 4; Strobe = Single (21 ch) / 29: DIM RGB DIM RGB S / Pixel = 4; Strobe = Single (17 ch) / 30: DIM RGBW DIM RGBW S / Pixel = 4; Strobe = Single (21 ch) / 31 DIM RGBAW RGBAW S / Pixel = 4; Strobe = Single (25 ch) / 32: RGB CCT DIM IND S / Pixel = 4; Strobe = Multiple (25 ch) / 33: RGBS RGBS / Pixel = 4; Strobe = Multiple (16 ch) / 34: RGB RGB SS / Pixel = 8; Strobe = Multiple (16 ch) / 35: RGBWS RGBWS / Pixel = 4; Strobe = Multiple (20 ch) / 36: RGBAWS RGBAWS / Pixel = 4; Strobe = Multiple (24 ch) / 37: DIM RGBS DIM RGBS / Pixel = 4; Strobe = Multiple (20 ch) / 38: DIM RGBWS DIM RGBWS / Pixel = 4; Strobe = Single (24 ch) / 39: DIM RGBAWS DIM RGBAWS / Pixel = 4; Strobe = Multiple (28 ch) / 40: RGB CCT DIM IND S / Pixel = 4; Strobe = Multiple (28 ch) / 41: RGB*RGB* / Pixel = 16; Strobe = Off (63 ch) / 42: RGB RGB / Pixel = 16; Strobe = Off (48 ch) / 43: RGBW RGBW / Pixel = 16; Strobe = Off (64 ch) / 44: RGBAW RGBAW / Pixel = 16; Strobe = Off (80 ch) / 45: DIM RGB DIM RGB / Pixel = 16; Strobe = Off (64 ch) / 46: DIM RGBW DIM RGBW / Pixel = 16; Strobe = Off (80 ch) / 47: DIM RGBAW DIM RGBAW / Pixel = 16; Strobe = Off (96 ch) / 48: RGB CCT DIM IND / Pixel = 16; Strobe = Off (96 ch) / 49: RGB*RGBS / Pixel = 16; Strobe = Single (63 ch) / 50: RGB*RGB S / Pixel = 16; Strobe = Single (49 ch) / 51: RGBW RGBW S / Pixel = 16; Strobe = Single (65 ch) / 52: RGBAW RGBAW S / Pixel = 16; Strobe = Single (81 ch) / 53: DIM RGB DIM RGB S / Pixel = 16; Strobe = Single (65 ch) / 54: DIM RGBW DIM RGBW S / Pixel = 16; Strobe = Single (81 ch) / 55: DIM RGBAW RGBAW S / Pixel = 16; Strobe = Single (97 ch) / 56: RGB CCT DIM IND S / Pixel = 16; Strobe = Single (97 ch) / 57: RGBS RGBS / Pixel = 16; Strobe = Multiple (64 ch) / 58: RGB RGB SS / Pixel = 16; Strobe = Multiple (64 ch) / 59: RGBWS RGBWS / Pixel = 16; Strobe = Multiple (80 ch) / 60: RGBAWS RGBAWS / Pixel = 16; Strobe = Multiple (96 ch) / 61: DIM RGBS DIM RGBS / Pixel = 16; Strobe = Multiple (80 ch) / 62: DIM RGBWS DIM RGBWS / Pixel = 16; Strobe = Multiple (96 ch) / 63: DIM RGBAWS DIM RGBAWS / Pixel = 16; Strobe = Multiple (112 ch) / 64: RGB CCT DIM IND S / Pixel = 16; Strobe = Multiple (112 ch) / 65: RGB*RGB* / Pixel = 8; Strobe = Off (31 ch) / 66: RGB RGB / Pixel = 8; Strobe = Off (24 ch) / 67: RGBW RGBW / Pixel = 8; Strobe = Off (32 ch) / 68: RGBAW RGBAW / Pixel = 8; Strobe = Off (40 ch) / 69: DIM RGB DIM RGB / Pixel = 8; Strobe = Off (32 ch) / 70: DIM RGBW DIM RGBW / Pixel = 8; Strobe = Off (40 ch) / 71: DIM RGBAW DIM RGBAW / Pixel = 8; Strobe = Off (48 ch) / 72: RGB CCT DIM IND / Pixel = 8; Strobe = Off (48 ch) / 73: RGB*RGBS / Pixel = 8; Strobe = Single (31 ch) / 74: RGB RGB S / Pixel = 8; Strobe = Single (25 ch) / 75: RGBW RGBW S / Pixel = 8; Strobe = Single (33 ch) / 76: RGBAW RGBAW S / Pixel = 8; Strobe = Single (41 ch) / 77: DIM RGB DIM RGB S / Pixel = 8; Strobe = Single (33 ch) / 78: DIM RGBW DIM RGBW S / Pixel = 8; Strobe = Single (41 ch) / 79: DIM RGBAW RGBAW S/ Pixel = 8; Strobe = Single (49 ch) / 80: RGB CCT DIM IND S / Pixel = 8; Strobe = Single (49 ch) / 81: RGBS RGBS / Pixel = 8; Strobe = Multiple (32 ch) / 82: RGB RGB SS / Pixel = 8; Strobe = Multiple (32 ch) / 83: RGBWS RGBWS / Pixel = 8; Strobe = Multiple (40 ch) / 84: RGBAWS RGBAWS / Pixel = 8; Strobe = Multiple (48 ch) / 85: DIM RGBS DIM RGBS / Pixel = 8; Strobe = Multiple (40 ch) / 86: DIM RGBWS DIM RGBWS / Pixel = 8; Strobe = Single (48 ch) / 87: DIM RGBAWS RGBAWS / Pixel = 8; Strobe = Multiple (56 ch) / 88: RGB CCT DIM IND S / Pixel = 8; Strobe = Multiple (56 ch) / 89: D CCT GM CRO RGB / Pixel = 1; Strobe = Off (7 ch) / 90: D CCT GM HUE SAT / Pixel = 1; Strobe = Off (5 ch) / 91: D16 CCT GM C RGB / Pixel = 1; Strobe = Off (8 ch) / 92: D16 CCT GM H SAT / Pixel = 1; Strobe = Off (7 ch) / 93: D16 X Y / Pixel = 1; Strobe = Off (6 ch) / 94: D CCT GM CRO RGB S / Pixel = 1; Strobe = On (8 ch) / 95: D CCT GM HUE SAT S / Pixel = 1; Strobe = On (6 ch) / 96: D16 CCT GM H SAT S / Pixel = 1; Strobe = On (8 ch) / 97: D16 X Y S / Pixel = 1; Strobe = On (7 ch) / 98: D CCT GM CRO RGB / Pixel = 4; Strobe = Off (28 ch) / 99: D CCT GM HUE SAT / Pixel = 4; Strobe = Off (20 ch) / 100: D16 CCT GM C RGB / Pixel = 4; Strobe = Off (32 ch) / 101: D16 CCT GM H SAT / Pixel = 4; Strobe = Off (28 ch) / 102: D16 X Y / Pixel = 4; Strobe = Off (24 ch) / 103: D CCT GM CRO RGB S / Pixel = 4; Strobe = Single (29 ch) / 104: D CCT GM HUE SAT S / Pixel = 4; Strobe = Single (21 ch) / 105: D16 CCT GM H SAT S / Pixel = 4; Strobe = Single (29 ch) / 106: D16 X Y S / Pixel = 4; Strobe = Single (25 ch) / 107: D CCT GM CRO RGB S / Pixel = 4; Strobe = Multiple (32 ch) / 108: D CCT GM HUE SAT S / Pixel = 4; Strobe = Multiple (24 ch) / 109: D16 CCT GM H SAT S / Pixel = 4; Strobe = Multiple (32 ch) / 110: D16 X Y S / Pixel = 4; Strobe = Multiple (28 ch) / 111: D CCT GM CRO RGB / Pixel = 16; Strobe = Off (112 ch) / 112: D CCT GM HUE SAT / Pixel = 16; Strobe = Off (80 ch) / 113: D16 CCT GM C RGB / Pixel = 16; Strobe = Off (128 ch) / 114: D16 CCT GM H SAT / Pixel = 16; Strobe = Off (112 ch) / 115: D16 X Y / Pixel = 16; Strobe = Off (96 ch) / 116: D CCT GM CRO RGB S / Pixel = 16; Strobe = Single (113 ch) / 117: D CCT GM HUE SAT S / Pixel = 16; Strobe = Single (81 ch) / 118: D16 CCT GM H SAT S / Pixel = 16; Strobe = Single (113 ch) / 119: D16 X Y S / Pixel = 16; Strobe = Single (97 ch) / 120: D CCT GM CRO RGB S / Pixel = 16; Strobe = Multiple (128 ch) / 121: D CCT GM HUE SAT S / Pixel = 16; Strobe = Multiple (96 ch) / 122: D16 CCT GM H SAT S / Pixel = 16; Strobe = Multiple (128 ch) / 123: D16 X Y S / Pixel = 16; Strobe = Multiple (112 ch) / 124: D CCT GM CRO RGB / Pixel = 8; Strobe = Off (56 ch) / 125: D CCT GM HUE SAT / Pixel = 8; Strobe = Off (40 ch) / 126: D16 CCT GM C RGB / Pixel = 8; Strobe = Off (64 ch) / 127: D16 CCT GM H SAT / Pixel = 8; Strobe = Off (56 ch) / 128: D16 X Y / Pixel = 8; Strobe = Off (48 ch) / 129: D CCT GM CRO RGB S / Pixel = 8; Strobe = Single (57 ch) / 130: D CCT GM HUE SAT S / Pixel = 8; Strobe = Single (41 ch) / 131: D16 CCT GM H SAT S / Pixel = 8; Strobe = Single (57 ch) / 132: D16 X Y S / Pixel = 8; Strobe = Single (49 ch) / 133: D CCT GM CRO RGB S / Pixel = 8; Strobe = Multiple (64 ch) / 134: D CCT GM HUE SAT S / Pixel = 8; Strobe = Multiple (48 ch) / 135: D16 CCT GM H SAT S / Pixel = 8; Strobe = Multiple (64 ch) / 136: D16 X Y S / Pixel = 8; Strobe = Multiple (56 ch) / 137: D16 CCT GM C RGB S / Pixel = 1; Strobe = On (9 ch) / 138: D16 CCT GM C RGB S / Pixel = 4; Strobe = Single (33 ch) / 139: D16 CCT GM C RGB S / Pixel = 4; Strobe = Multiple (36 ch) / 140: D16 CCT GM C RGB S / Pixel = 16; Strobe = Single (129 ch) / 141: D16 CCT GM C RGB S / Pixel = 16; Strobe = Multiple (144 ch) / 142: D16 CCT GM C RGB S / Pixel = 8; Strobe = Single (65 ch) / 143: D16 CCT GM C RGB S / Pixel = 8; Strobe = Multiple (72 ch) / 168: D CCT GM C CRO XY / Pixel = 1; Strobe = Off (8 ch) / 169: D16 CCT GM C CRO XY / Pixel = 1; Strobe = Off (9 ch) / 170: D CCT GM C CRO XY S / Pixel = 1; Strobe = On (9 ch) / 171: D16 CCT GM C CRO XY S / Pixel = 1; Strobe = On (10 ch) / 178: D CCT GM C CRO XY / Pixel = 4; Strobe = Off (32 ch) / 179: D16 CCT GM C CRO XY / Pixel = 4; Strobe = Off (36 ch) / 180: D CCT GM C CRO XY S / Pixel = 4; Strobe = Single (33 ch) / 181: D16 CCT GM C CRO XY S / Pixel = 4; Strobe = Single (37 ch) / 182: D CCT GM C CRO XY S / Pixel = 4; Strobe = Multiple (36 ch) / 183: D16 CCT GM C CRO XY S / Pixel = 4; Strobe = Multiple (40 ch) / 184: D CCT GM C CRO XY / Pixel = 8; Strobe = Off (64 ch) / 185: D16 CCT GM C CRO XY / Pixel = 8; Strobe = Off (72 ch) / 186: D CCT GM C CRO XY S / Pixel = 8; Strobe = Single (65 ch) / 187: D16 CCT GM C CRO XY S / Pixel = 8; Strobe = Single (73 ch) / 188: D CCT GM C CRO XY S / Pixel = 8; Strobe = Multiple (72 ch) / 189: D16 CCT GM C CRO XY S / Pixel = 8; Strobe = Multiple (80 ch) / 190: D CCT GM C CRO XY / Pixel = 16; Strobe = Off (128 ch) / 191: D16 CCT GM C CRO XY / Pixel = 16; Strobe = Off (144 ch) / 192: D CCT GM C CRO XY S / Pixel = 16; Strobe = Single (129 ch) / 193: D16 CCT GM C CRO XY S / Pixel = 16; Strobe = Single (145 ch) / 194: D CCT GM C CRO XY S / Pixel = 16; Strobe = Multiple (144 ch) / 195: D16 CCT GM C CRO XY S / Pixel = 16; Strobe = Multiple (160 ch) |
| Long name | Astera AX2 100 |
| Beam angle | 21° |
| Dimensions | 1020 × 137 × 65 mm |
| Short name | Astera AX2 100 |
| Color wheel | 150 colors + open |
| DMX channels | 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 12 / 13 / 15 / 16 / 17 / 20 / 21 / 24 / 25 / 28 / 29 / 31 / 32 / 33 / 36 / 37 / 40 / 41 / 48 / 49 / 56 / 57 / 63 / 64 / 65 / 72 / 73 / 80 / 81 / 96 / 97 / 112 / 113 / 128 / 129 / 144 / 145 / 160 |
| Fixture UUID | A9408E0D-C8B7-432E-84D1-BE4878256401 |
| GDTF version | 1.2 |
| Luminous flux | 4 460 lm |
| Color temperature | 5500 K |
| Operating temperature | 0 to 40 °C |
